Page 57: Work Zone Roadway Condition Signs (W1-4, W8 C-Series, W24-1, W16-2)

Page 57 of the Rice Signs 2017 Traffic Safety Catalog covers the Work Zone Roadway Condition Signs — orange work-zone variants of the standard yellow W1, W6, W8, W16, and W24 MUTCD warning signs. These signs use the "c" suffix (e.g., W8-4c, W8-7c) to indicate the work-zone-orange background color required by MUTCD Chapter 6 for active construction zones. Categories on this page: W1-4 Combination Curve direction-change signs for advance warning of changing road geometry through a work zone (6 variants — bL, bR, cL, cR, LC, RC); W8 C-Variants for shoulder, gravel, uneven lanes, and grooved pavement conditions in work zones; W24-1 Lane Shift signs (6 variants including a- and b-suffix) for lateral lane shifts during construction; and W16-2cp distance plaques marking distance to a work-zone hazard (500 ft, 1000 ft, 1500 ft).

BACK Rice Signs catalog page 57 — Work Zone Safety section showing orange work-zone variants of MUTCD warning signs — W1-1 and W1-2 Curve and Turn signs in work-zone orange, W1-4 Combination Curve direction-change signs in six variants (bL, bR, cL, cR, LC, RC), W6-2 and W6-3 Divided Highway signs in work-zone orange, W8-4c Soft Shoulder, W8-6c Uneven Lanes, W8-7c Loose Gravel, W8-11c Uneven Lanes Ahead, W8-15c Grooved Pavement with W8-15cP plaque, W8-17c Uneven Pavement, W24-1 Lane Shift signs in six variants, and W16-2cp distance plaques in 500, 1000, and 1500 ft. Reverse Curve LeftTwo Lane Reverse Curve LeftThree Lane Reverse Curve LeftDouble Reverse Curve Left One LaneDouble Reverse Curve Left Two Lanes Double Reverse Curve Left Three LanesRoad NarrowsNarrow BridgeOne Lane BridgeTwo Way TrafficBumpDipPavement EndsSoft ShoulderSlippery When WetTruck CrossingLoose GravelRough RoadLow ShoulderUneven LanesGrooved PavementShoulder Drop Off (symbol)No ShoulderSteel Plate AheadShoulder EndsMotorcycle (plaque)Shoulder Drop-off500 Feet 1000 Feet 1500 Feet NEXT
