Page 20: Warning Signs — Horizontal Alignment (W1 Series)

Page 20 of the Rice Signs 2017 Traffic Safety Catalog begins the Warning Signs section with general specifications for diamond-shaped yellow warning signs (0.080 aluminum substrate, rolled edges, Engineer Grade or HIP reflective sheeting with 6, 7.5, or 10-year warranties in standard sizes from 24 by 24 inches up to 48 by 48 inches), followed by the W1 series Horizontal Alignment Signs. These signs alert drivers to upcoming turns, curves, and changes in road alignment: W1-1 Turn signs for sharp turns, W1-2 Curve signs for gradual curves, W1-3 Reverse Turn for two consecutive turns, W1-4 Combination Curve / Reverse Curve direction change signs, W1-5 Winding Road for three or more curves, W1-6 Large Arrow signs at apex, W1-7 Two-Direction Arrow for T-intersections, and W1-8 Chevron Alignment Signs for marking the inside of a curve.

BACK Rice Signs catalog page 20 — start of the Warning Signs section showing diamond-shaped yellow warning sign specifications, 0.080 aluminum substrate details, reflective performance table comparing Engineer Grade, HIP, and Diamond Grade sheeting service life, and Horizontal Alignment Signs including W1-1 Turn left and right signs, W1-2 Curve left and right signs, W1-3 Reverse Turn signs, W1-4 Combination Curve direction change signs, W1-5 Winding Road, W1-6 Large Arrow, W1-7 Two-Direction Arrow, and W1-8 Chevron alignment signs. Turn RightTurn LeftCurve RightCurve LeftReverse Turn Right Reverse Turn LeftTurn Right With SpeedTurn Right With Speed Limit Curve Right With Speed LimitCurve Left With Speed LimitReverse Curve RightReverse Curve LeftWinding Road RightWinding Road LeftChevron AlignmentLarge Single ArrowLarge Double ArrowHazard Board NEXT
